Specifications#

General Specifications#

Parameter	Min	Typ.	Max	Units
Input Voltage	–	–	24	V
Free speed @ 12V	–	6780	–	RPM
Free current @ 12V	–	2.0	–	A
Continuous Current	–	60	–	A
Peak Current (5s)	–	–	120	A
Operating Temperature	-20	–	100	°C
Weight (with wires)	–	1.1	–	lb
kV	–	565	–	RPM/V
kT	–	0.0165	–	N*m/A
Stall Current (12V)	–	440	–	A
